KY-023 Dual-Axis XY Joystick Module PS2 Control Lever Sensor for Arduino, ESP32 & Raspberry Pi

Description

The KY-023 Dual-axis XY Joystick Module is a compact PS2-style control lever sensor designed for Arduino, ESP32, Raspberry Pi, STM32, and other microcontroller platforms. It provides precise analog control on both the X and Y axes using two built-in 10kΩ potentiometers, making it ideal for robotics, RC vehicles, gaming controls, camera pan/tilt systems, and DIY interactive projects. The module also includes an integrated push-button switch that activates when the joystick is pressed downward, giving you an additional digital input for menu selection, action control, or special functions. When centered, the joystick outputs approximately half the supply voltage, allowing easy detection of mov

Key Features

• Dual-axis analog joystick for X and Y movement control
• Built-in push-button switch for Z-axis click function
• PS2-style joystick with smooth spring return to center
• Two analog outputs (VRx and VRy)
• One digital output (SW) for button press detection
• Uses two internal 10kΩ potentiometers
• Neutral output approximately half of supply voltage
• 5-pin interface: GND, VCC, VRx, VRy, SW
• Compatible with Arduino, ESP32, Raspberry Pi, STM32, AVR, and PIC
• Standard 2.54mm pin spacing for breadboards and jumper wires
• Ideal for robot control, RC vehicles, gaming interfaces, camera control, and menu navigation
• Self-centering joystick mechanism for accurate control

Specifications
